MIL-DTL-484J
TABLE IV. End item tests. - Continued
Requirement
Characteristic
paragraph
Test method
Water repellent treatment: 3/
(cont'd)
Hydrostatic pressure:
Initial
3.7.1
AATCC-127
After 3 launderings
3.7.1
AATCC-127 AATCC 96 VIc 4/
Spray rating:
Initial
3.7.1
AATCC-22
pH
3.8
AATCC-81
Resistance to organic liquid:
Initial
3.9
AATCC-118
After 15 laundering
3.9
AATCC-96, VIc 3/ AATCC-118
Dimensional stability
3.10
AATCC-96, VIc 5/
Seam efficiency
3.11
ASTM D 1683 6/
Toxicity
3.16
4.4.2
1/ One determination shall be made from each sample unit and the results reported as "pass" or
"fail.".
2/ The contractor shall report the water repellents used and certify that no other material
(except the specified buffer and acetic acid) has been added.
3/ The last two wash cycles shall be performed without the use of detergent. The specimens
shall be dried after each laundering.
4/ An additional laundering procedure shall be performed without the use of detergent. The
specimens shall be dried after each laundering..
5/ The dimensional stability shall be performed after 1 cycle. The cloth shall not be pressed
after tumble drying prior to measurement.
6/ The thread shall conform to Type B of V-T-295 using seam Type LSc-2 and stitch Type 301
or 401 as specified in ASTM D 6193 using 12 + 1 stitches per inch. A needle size 0.04 + 0.001
inch shall be used for Type I and 0.036 + 0.001 inch shall be used for Type VI.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in
the contract or order (see 6.2). When actual packaging of material is to be performed by DoD or
in-house contractor personnel, these personnel need to contact the responsible packaging activity
to ascertain requisite packaging requirements. Packaging requirements are maintained by the
Inventory Control Point's packaging activities within the Military Department or Defense
Agency, or within the military service's system commands. Packaging data retrieval is available
from the managing Military Department's or Defense Agency's automated packaging files, CD-
ROM products, or by contacting the responsible packaging activity.
9
