MIL-DTL-44050B
TABLE II. Component and end item tests.
REQUIREMENT
CHARACTERISTICS
TEST METHOD
PARAGRAPH
Fiber identification
3.2.1
AATCC 20A
Yarn denier
3.2.2
ASTM D1907
Yarn breaking tenacity
Warp
3.2.2.1
ASTM D885
Types I and IA
Filling
3.2.2.1
ASTM D885
Yarn twist
3.2.2.1
ASTM D1423 or D1422
Warp
3.2.2.2
ASTM D885
Types II
Filling
3.2.2.2
ASTM D885
Yarn twist
3.2.2.2
ASTM D1423 or D1422
Warp
3.2.2.3
ASTM D885
Types III
Filling
3.2.2.3
ASTM D885
Yarn twist
3.2.2.3
ASTM D1423 or D1422
Warp
3.2.2.4
ASTM D885
Types IV
Filling
3.2.2.4
ASTM D885
Yarn twist
3.2.2.4
ASTM D1423 or D1422
Warp
3.2.2.5
ASTM D885
Types V
Filling
3.2.2.5
ASTM D885
Yarn twist
3.2.2.5
ASTM D1423 or D1422
ASTM E805 or Visual 1/
Color
3.3
Weight
3.4
ASTM D3776
Warp
3.4
ASTM D3775
Yarns per inch
Filling
3.4
ASTM D3775
2/
Warp
3.4
ASTM D885
Yarn break force (lbf)
2/
Filling
3.4
ASTM D885
Water repellency (Class
Initial
3.4
AATCC 70
2), Dynamic Absorption
After one laundering
3.4
AATCC 96 and AATCC 70
Adhesion modified, Water
Initial
3.4
AATCC 70
1/
repellency (Class 3),
Weave
3.6
Visual
Dynamic Absorption (%
3/
Finish (all Classes)
3.7
weight increase)
Initial
3.8
AATCC 22
Spray rating (Class 2)
After one laundering
3.8
AATCC 96 and AATCC 22
Resistance to organic
Initial
3.9
4.5.1
liquid (Class 2)
After one laundering
3.9
AATCC 96 and 4.5.1
Ballistic limit (Type I)
3.10.1
4.5.2
Bullet resistance (Type IA)
3.10.2
4.5.3
Ballistic limit (Type II)
3.10.3
4.5.4
Ballistic limit (Type III)
3.10.4
4.5.4
Ballistic limit (Type IV)
3.10.5
4.5.4
Ballistic limit (Type V)
3.10.6
4.5.4
Toxicity
3.14
4.5.7
1/
One determination shall be made from each sample unit and the results reported as "pass" or "fail". Visual
inspection of the delivered fabric compared to manufacturer's standard product shall be determined.
2/
For the Type I and IA cloth, clamps with flat-grip type jaws may be used. For Type II cloth, the yarn shall be
tested using a constant rate of extension (CRE) tensile testing machine set with a 10 ± 0.05 inch gage length and
operated at 5 inches per minute speed. The yarn shall be tested at 1.5 turns per inch twist for Types I, IA and II
cloth, 1.5 turns per inch for Type IV cloth, 2.8 turns per inch Z twist for Type III, and 3.3 turns per inch twist for
Type V cloth. Twist may be added or removed as appropriate, but care must be taken to handle the yarn in such a
manner that the twist does not deviate from the required twist level per inch prior to closing the jaws of the clamps
on the specimen.
3/
Documentation shall be provided for all Classes stating the finish or lack of finish present.
9
