MIL-DTL-44031E
3.6 Physical requirements. The finished cloth shall conform to the requirements in
Table IV when tested as specified in 4.4.3.
TABLE IV. Physical requirements
Characteristic
Classes 1, 3, 5, 6 and 7
Classes 2, 4 and 8
Weight (oz./sq.yd.), min.
6.8
7.0
Construction, (yarns per inch), min.
Warp
86
86
Filling
54
54
Breaking strength (pounds), min.
Warp
200
190
Filling
125
115
Tearing strength (pounds), min.
Warp
11
10
Filling
8
7
Air permeability
25.0
10.0
(cu.ft/minute/sq. ft), min.
Electrostatic Decay (Class 3 and Class 5)
Initial and after five launderings
See 3.10
See 3.10
3.6.1 Weave. The weave shall be a 2/1 left hand twill.
3.6.2 Width. For Government procurements only, the width of the cloth shall be as specified
(see 6.2) and shall be the minimum acceptable width inclusive of the selvage when fly-shuttle
looms or shuttleless with tuck-in selvage are used. For all other shuttleless looms, the width
measurement shall be made between the last warp yarn on each side excluding the protruding
fringe(s).
3.7 Finish. The cloth shall be dyed and printed with the warp effect side as the face. The
cloth shall be, desized, scoured, dyed, and printed. The Class 2, 4 and 8 cloths shall be given a
water repellent treatment as specified in 3.7.1.
3.7.1 Water repellency (Class 2, 4 and 8). The cloth shall be given a fluorocarbon (Quarpel
Type) water repellent treatment meeting the requirements specified in Table V and 3.9. Testing
shall be as specified in 4.4.3.
TABLE V. Water repellency (Class 2, 4 and 8)
Hydrostatic height
Dynamic absorption (percent)
(centimeters)
Spray rating
max. 1/
min.
(min)
Initial
20
18.0
100, 100, 90
After 15 launderings
20
18.0
----
1/ No individual specimen shall exceed the specified maximum.
9
