MIL-DTL-823L
IDENTIFICATION TAG
OR TICKET
.1875 INCH MIN, WALL THK., 1.5 INCHES MIN. I.D. TUBE FLUSH
OR EXTENDED NOT MORE THAN 1 INCHI BEYOND EACH SIDE OF FABRIC
PROCESSING METHOD
MATERIAL FOLDED AND
OVERLAPPED TO PROJECT END
GUMMED TAPE 2-1/2
INCIHES WIDE
BASIC WRAPING METHOD
BOTTOM CLOSURE
TOP CLOSURE FOLDED
FOLDED AND SEWN
AND TAPED
BASIC WRAPPING METHOD ALTERNATE
Figure 2. Processing and Wrapping of Rolls
36p16" style="font-size:12px">16
